Brand name

4H HD Surgery Field Camera

Image Sensor

1 / 2.5  inch  Exmor R CMOS

Effective pixels

Approximately 8.51 million pixels

Lens

Optical zoom: 20 times

4.4 mm {f = wide} ~ 88.4 mm (Tele)    , of F2.0 F3.8 ~

signal system

4k

2160p / 29.97, 2160p / 25

FHD / HD

1080p / 59.094, 1080p / 50, 1080i / 59.94, 1080i / 50, 720p / 59.94, 720p / 50

Minimum illumination

High sensitivity mode

Color: 0.75 lx (F1.8, AGC on, 1 / 30s)

-50%

Normal mode

Color: 3lx (F1.8, AGC on, 1 / 30s)

Shutter speed

1 /1 sec to 1 / 10,000 sec, 22 steps Order

Synchronization system

Internal synchronization

Exposure control

Auto, manual, priority mode (shutter priority & aperture priority )

Brightness, EV compensation, slow EV

White balance

Automatic, automatic tracking white balance, indoor, outdoor, outdoor auto, sodium lamp

(Fixed / auto / outdoor automatic ), one-button, manual

Focusing system

Auto (sensitivity: normal, low), one-button auto focus, manual, interval auto focus

Zoom triggers autofocus, focus compensation when ICR mode is on

Minimum object distance

10mm (wide-angle end) to 1500mm ( far end ) (default: 300mm )

Image output

HDMI output

Image effects

Electronic flip, negative, black and white, mirror, color enhancement

HD video output

Number: Y / CB / CR 4: 2: 2 8 -bit component, R / G / B 4: 4: 4 8 -bit component

Camera component control interface

VISCA (CMOS 5V level ) , baud rate: 9.6kbps, 19.2kbps

38.4kbps, 115.2kbps, stop bit: 1 bit

Power requirements

6.0V to 12.0V DC

Power consumption

Approximately 6.8K

weight

3.2KG
