AHD ZOOM All in one Camera WDR OSD RS-485 30X zoom SZ-AR8318-P2H_SafeEye

1)AHD 2.0 Megapixel CMOS sensor

2) Plug and play technology

Model	SZ-AR8318-P2H
mage Sensor	IMX322 1/2.8 inch 2.0 Mega
Lens Parameter	Lens:30X 3.9~117MM FNo: 1.6~3.5
Max. Resolution	1920x1080
Frames per second	25/30
Min. Illumination	0.001 lux
Output Format	1080P/25 AHD, 1080P/30 AHD
Denoise	2D/3D
Optical zoom	30X
Digital zoom	10X
Auto IRIS	YES
AF mode	Normal/Zoom Trigger/Interval
AWB mode	Auto/Manual/outdoor/indoor
AE mode	Auto/shutter priority/IRIS priority/manual
Electronic shutter	1/25~1/10000
IR cut mode	Auto/day/night
Privacy Zone	24Mask
OSD	Title/Display
Interface	9 Pin FPC
Protocol	SONY VISCA
Dimension (W/H/D)	50 x 60 x 96.2mm
Weight	270g
Power	240mA
Operating Temprature	-20℃ ~ +60℃
