Main Features:
1,Built-in 1 / 2.8-type "Exmor" CMOS sensor, 2.38 million pixels, 1920 * 1080P, HD 1080P Real-time image
2,Support HD signal, 30x optical zoom , 12 times digital zoom
3,Support different types of output: 1080P60 frames / 50 frames, 1080P30 frames / 25 frames, 1080I / 60 frames / 50 frames, 720P60 frames / 50 frames, etc.
4,Support RS485 protocol PELCO-D, PELCO -P, baud rate 2400/4800/9600/19200/38400, address code 1----255 optional
5,Support SONY VISCA protocol
6,With OSD menu function
7,Unique installation site standard definition image viewing function, easy On-site debugging with standard-definition engineering treasures.
8,Lens power-off memory function
9,HD-SDI high-definition and analog three-component high-definition signal synchronization output, can also set a separate standard definition output.
10,Support infrared external synchronization, can switch color to black function synchronously with infrared light.
11,Preset position function, with 10 preset positions, you can set the cruise, automatically call the preset position.
|
Product
number
|
SDI-7520
|
|
Image Sensor
|
1/2.8-type “Exmor” CMOS
|
|
Image format
|
1920*1080 1280*720
|
|
Output
format
|
1080P/60 1080P/50 1080P/30 1080P/25 1080i/60 1080i/50 720P/60 720P/50
|
|
Resolution
|
About 2.38
million pixels
|
|
Lens
|
30x optical
zoom, f=4.3 mm (wide) ~ 129 mm (tele), F1.6 ~ F4.7
|
|
12x digital
zoom
|
|
Minimum
illumination
|
0.35 lux
(ICR OFF)
|
|
0.013 lux
(ICR ON)
|
|
Horizontal
viewing angle
|
63.7 (near
end) --- 2.3 degrees (remote)
|
|
White
balance
|
ATW/Auto
Tracking White Balance / Auto White
Balance / Manual White
Balance/Indoor / Outdoor
|
|
Focus
control
|
On/off
(automatic/manual)
|
|
Wide dynamic
|
automatic
switch
|
|
Anti-shake
|
switch
|
|
Fog
|
switch
|
|
Electronic
noise reduction
|
On/Off (1-5)
adjustable
|
|
Electronic
shutter
|
1/1—1/10000s total
22 files
|
|
Trust ratio
|
Greater than
50dB
|
|
aperture
|
Automatic /
manual (adjustable) a total of 16
|
|
Gain
|
Automatic /
manual (-3 dB ---28 Db) a total of 16 files
|
|
BLC
|
switch
|
|
Night vision
switching
|
Auto / color
/ black and white
|
|
Privacy
masking
|
4 groups
|
|
Preset
|
10
|
|
output
signal
|
HD-SDI/YPbPr,
CVBS
|
|
communication
method
|
RS485 (PELCO P/D
protocol) remote control RS-232
|
|
OSD menu
|
stand by
|
|
Infrared
external synchronization
|
stand by
|
|
Operating
temperature
|
-5°C~60°C
(indoor)
|
|
power supply
|
DC12V 2A
|
|
power
|
6W
|
|
weight
|
Telephone
consultation
|
|
size
|
120(D)*60(W)*70(H)mm
|
|
Standard
accessories
|
Product
manual, 3.81 pitch 8-bit terminal, 8-pin DuPont line, three-component video
cable, certificate, lens cloth
|
