Product name

SDI-6300

Imaging device

1/2.8-type Exmor CMOS

Effective Pixels

Approx  2M  pixels

Image mode main output

1080P/30 frames, 1080P/25 frames, 1080i/60 frames, 1080i/50 frames, 720P/60 frames, 720P/50 frames

optical zoom

20x  times,  f=4.7  mm  (wide)  ~  94  mm  (tele),   F1.6  ~  F3.5

Electronic zoom

12x

Minimum illumination

0.5   lux

White balance

ATW/Auto Tracking White Balance  /  Auto White Balance  /  Manual White Balance/Indoor  /  Outdoor

Focus control

On/off (automatic/manual)

Wide dynamic

automatic switch

Electronic noise reduction

2D,  5  steps  +   ChromaSuppress  3  steps

Electronic shutter

1/1  to  1/10,000  s,  total  22   steps

Trust ratio

50dB in size

aperture

CLOSE, F1.2, F1.4, F1.6, F2, F2.4, F2.8, F3.4, F4, F5.6, F6.8, F8, F9.6

Gain

-3dB, 0dB, 2dB, 4dB, 6dB, 8dB, 10dB, 12dB, 14dB, 16dB, 18dB, 20dB, 22dB, 24dB, 26dB, 28dB

BLC

BLC  /HLC  /  OFF

Color to black

Auto / color / black and white

OSD menu

stand by

Related certification

RoHs  , CE, FCC

Operating temperature

-5°C~60°C (indoor)

power supply

DC12V  2A

power

5W

communication method

RS485 and infrared remote control

Video output

HD-SDI
