Camera
|
|
Image sensor
|
1/3-type CMOS (Progressive Scan)
|
Gamma
|
Standard/Straight gamma
|
|
Effective number of pixels
|
Approx. 4,080,000 pixels
|
Aperture control
|
16 steps
|
|
Signal system(HD)
|
1080p/60, 1080p/50, 1080p/30, 1080p/25, 1080i/60,
1080i/50, 720p/60, 720p/50
|
White balance
|
ATW1(Narrow), ATW2(Wide), One push, Manual (B, R)
|
|
Minimum illumination
|
0.5 lx (1/30sec, F1.8, 50%)
|
AE
(Auto exposure mode)
|
Auto, Manual, Priority mode (shutter/iris)
|
|
Recommended illumination
|
100 lx to 100,000 lx
|
Lens (wide to tele)
|
10x optical zoom ｆ＝3.3 to 33.0 mm F1.8 to 3.4
|
|
S/N ratio
|
More than 50dB
|
Zoom mode
|
Standard /Variable/Direct
|
|
Gain
|
Auto / Manual
|
Zoom movement speed
(wide to tele)
|
1.4 sec (Focus Tracking ON)
|
|
Shutter speed
|
1/1 to 1/10,000 sec
|
Focusing system
|
Auto, Manual, One push, AF sensitivity
|
|
Sync system
|
Internal
|
Horizontal viewing angle
(wide to tele)
|
59.2° to 6.7°
|
|
Exposure compensation
|
-12dB to +12dB (Total 13 steps)
|
Minimum object distance
(wide to tele)
|
10mm to 800mm
|
|
Backlight compensation
|
ON/OFF
|
Horizontal resolution
|
800 TV lines
|
|
Functions
|
VC
(Vibration Compensatin)
|
Available
|
Picture effects
(Black White)
|
Available
|
|
Wide-D
|
Available
|
Picture freeze
|
Available
|
|
Defog
|
Available
|
Electronic-Flip (E-Flip)
|
Available
|
|
Noise reduction (3D + 2D)
|
Available
|
Mirror image
|
Available
|
|
Digital output
|
Available
|
Teamperature readout
|
Available
|
|
Privacy zone masking
|
Available
|
Title display
|
Available
|
|
Slow shutter
|
Available
|
|
|
|
General
|
|
Power requirement
|
8 V to 12 V DC
|
Operating humidity
|
20% to 80% (no condensation)
|
|
Power consumption
|
Approx. 3W
|
Storage humidity
|
20% to 90% (no condensation)
|
|
Operating temperature
|
-5 °C to +60°C
|
Dimensions
(W x H x D)
|
31.9 x 41.5 x 58.4 mm
|
|
Storage temperature
|
-40 °C to +60°C
|
Weight
|
Approx. 77g
|
|
Interface
|
|
Video output
|
Digital: Y/Pb/Pr 4:2:2 (LVDS)
|
Camera control interface
|
VISCA protocol
*VISCA is a tragemark of Sony Corporation.
|
